APPENDIX D

Catalyst Enterprises, Inc.

241

External Signals

Pin 1 is square pad.

JP16 is for factory use only.

* Not Implemented

JP15

Pin

Pin

Ext_In0

1

2

Ext_In1

Ext_In2

3

4

Ext_In3

Ext_In4

5

6

Ext_In5

Ext_In6

7

8

Ext_In7

Ext_In8

9

10

Ext_In9

Ext_In10

11

12

Ext_In11

Ext_In12

13

14

Ext_In13

Ext_In14

15

16

Ext_In15

Ext_O0 *

17

18

Ext_O1 *

Ext_O2 *

19

20

Ext_O3 *

GND

21

22

GND

GND

23

24

Key
