Catalyst Enterprises Inc. Library Exported Interfaces
202
SetTimingMasks(ptrTimingMasks)
Parameters
ptrTimingMasks Specifies the Value of the Signal Masks parameter for next run.
The order of the Timing mask is shown below:
“AD[64], CBE[8], PAR, PAR64, PERR, SERR, REQ, GNT,
REQ64, ACK64, STOP, LOCK, RST, INTA, INTB, INTC, INTD,
FRAME,TRDY, IRDY, DEVSEL, IDSEL, PME”
For example:
AD[0]->ptrTimingMasks[0]
AD[1]->ptrTimingMasks[1]
GetTimingMasks(ptrTimingMasks)
Parameters
ptrTimingMasks The Value of Signal Masks parameter returned.
The order of the Timing mask is shown below:
“AD[64], CBE[8], PAR, PAR64, PERR, SERR, REQ, GNT,
REQ64, ACK64, STOP, LOCK, RST, INTA, INTB, INTC, INTD,
FRAME,TRDY, IRDY, DEVSEL, IDSEL, PME”
For example:
ptrTimingMasks[0] -> AD[0]
ptrTimingMasks[1] ->AD[1]
SetTimingMaskAll(bMaskValue)
Parameters
bMaskValue Specifies the Value of all Signal Masks parameters for next run.
Remarks SetTimingMaskAll method sets the Value of Timing Masks parameter
for next run by bMaskValue.
SetTimingMasksAddress(bAdd32, bMaskValue)
Parameters
bAdd32 Specifies the mode of Masking for address signals. If it will be true
the masking is on the Address 32bits els on all address signals.
TRUE: Masking is on 32 bits of address
FALSE: Masking is on all address signals
bMaskValue Specifies the value of Masking for address signals.
