Advanced Mode Catalyst Enterprises, Inc.
65
Advanced Mode
The Advanced Mode expands the analyzer capability by allowing you to program
special custom debugging projects and define complex triggering levels. Such projects
are programmed by defining event patterns for triggering and triggering sequences om
convenient Event Pattern definition and Sequencer programming menus.
The State & Timing analyzer configuration, in addition to the special programming
with event and sequencer files, also expands the Timing Violation Analysis by
allowing you to chose leading and trailing edge timing values.
With this expanded capability you may perform all of the same analysis functions as
in the Easy Mode but with much customizing.
• Setup complex triggering level to Capture data and trigger using
custom projects.
• Perform timing characterization timing violation detection.
• Capture bus activity and the device under test response under
different conditions using the exerciser.
• Do Performance Analysis on PCI bus activities.
• Measure and report Statistics on selected parameters.
Easy Mode Access As a convenience to allow you to get a quick snapshot of bus activity, the
Advanced Mode menu bar includes a Yellow button that gives you access
to an Enhanced Easy mode.
Enhanced Easy Mode Accessing the Easy mode from the Advanced mode expands the exerciser
programming capability to include program loops
