Catalyst Enterprises, Inc. Display Manipulation
142
Figure 130 Search Pattern Definition Dialog Box (D32 XFER)
1. Set the search parameters and address or parameter pattern that you wish to
locate and click OK.
Search Settings Retained The search settings for each search are retained for future use, unless
cleared by clicking the Clear List button. To search with previously
defined settings, highlight the appropriate line and click OK.
Figure 131 Search Settings Retained
Each time you initiate a new search, an unconfigured search line is added
to the list. You may use it to set up new search parameters or use one of
the previously defined ones.
Search Also You may expand your search to include Virtual Address Pattern, Protocol
Errors Pattern and/or External Signals Pattern or termination type by
checking the appropriate check box in the Search Also area.
