Installing Your Analyzer Catalyst Enterprises, Inc.
5
Installing Your Analyzer
Hardware Installation
1. Make sure that the Target Machine is powered down.
2. Remove the case from your machine in accordance with the instructions
supplied for it.
3. Install the Analyzer card in any available PCI slot and secure the mounting
bracket to the chassis with the mounting screw.
4. Interconnect the Host system’s bi-directional parallel port, USB port or ethernet
using the cables provided.
Host and Target Same The Analyzer may be used in a configuration such that the Host and
Target are the same machine.
Bi-Directional Port The Analyzer requires that The Host parallel port support Bi-directional
data transfers. See LPT Port Setting for verifying that your parallel port
supports and/or is set to a Bi-directional mode. If the parallel port on your
Host system does not support Bi-directional data transfers you must then
install a parallel port card that supports bi-directional data transfers.
Port Configuration Make sure that the installed parallel port card address does not conflict
with an existing parallel port such as one for a printer.
Software Installation
On systems operating under Windows 2000 or XP:
1. Insert the CD-ROM.
2. The installation will automatically start the setup unless the auto Run is turned
off, in that case select the CD-ROM from “My Computer” and click on setup.
3. After the warning for closing all other programs and before starting the
installation, the Install Component selection window will open as shown in
Figure 4.
Warning: Make sure to take precautions to avoid static electricity discharge
damage to the Analyzer Card by using a grounding strap or touching
a grounded metal surface just prior to handling the analyzer card.
Avoid touching any components and handle card by the edges only.
