Configuration Menu Catalyst Enterprises, Inc.
19
Click the down arrow next to the Host Bus Type list box and select the bus type of
your system.
If your protocol selection does not correspond to your Host Bus selection you will get
a bus mismatch warning message.
Change the protocol to match the detected systen bus by clicking the down arrow on
the Working Mode selection list box and choose the required protocol.
Figure 8 Protocol Selection
