Catalyst Enterprises, Inc. Custom Capture Data Project
76
The data capture choices for every state are:
All Captures all data on every cycle
None Captures no data
EV1 - EV8 Captures data as specified for each events
!EV1-!EV8 Captures all data outside the specified address or
data range
Expression Captures data as defined by a Boolean
expression
The state transition events for every state are:
Any Unconditional
Protocol Error A Protocol Error
Timing Error Only in PCI Timing Analyzer. Not supported
on TA700PDC (PMC) and TA800.
EV1 - EV8 Predefined events
!EV1-!EV8 If not pre-defined
Expression A Boolean equation of events. e.g. EV1+!EV2
External External signals
