Jumper Configuration

TA800 +3.3V Power Source selection

External Power

External +5V connects to JP6 Pins 1 & 2 Gnd is pin 3. JP6 is keyed to
mate with the Catalyst power supply.

Trigger Out

J7 Pin 1, gnd J7 pin 2 see Figure 163.

External Outputs:

Bus Protocol & Speed Sensing

JP7

Shunt 1-2 top to center

+3.3V from on board 5V regulator

Shunt 2-3 bottom to center

+3.3V Bus Power (Default)

JP1

1 thru 4

External Outputs [0:3]

5 thru 8

GND

JP2

Shunt 1-2 Top two

PCI-X 133MHz (Default)

Shunt 3-4 Next to top

PCI-X 66MHz

Shunt 5-6 Next to bottom

PCI
