TA700/800 SPECIFICATIONS Catalyst Enterprises, Inc.
183
UTILITIES
Search By name, forward, backward and for consecutively re-occurring patterns.
Post-capture filter Include or exclude use-defined patterns.
Convert Captured Data ASCII
EXCEL
PCX
Compare Captured Data User defined start and end from each file
Jump
Jump in results display relative to X and Y trigger positions from starting
position.
Capture Screen Capture a mouse cursor selectable screen area for saving as a *.pcx file.
Zoom Zoom display around X and Y cursors, between X and Y cursors or Zoom
around independently of cursors.
MNEMONICS
100 User Defined per file May be saved for recall in a different application. Unlimited files may be
generated and saved.
PCI Bus Inverse decode of all PCI initiator and target termination.
EXERCISER
Bus Width Up to 64 Bit
Bus Speed 25 to 66.6 MHz
1 KHz to 133.33 MHz PCI-X for TA800
1 KHz to 66.6 MHz for TA700PDC
Output Voltage Swing 3.3 V
Link To the Analyzer, Start after defined events, Start after external trigger
Data Block generation
Data block generation of W1, W0 or user patterns
8, 16, 32 or 64 bit wide
Up to 128K deep
Multiple blocks of data in to a single file
May be generated in the GUI and saved as ASCII format
May be generated in a text editor and imported to the exerciser program
