Expressscope® monitor lcd timeouts, Navigating menus – NEC ExpressA1160 User Manual
Page 93
Menu System
4-7
•
Return to the main screen
The main menu appears on the EXPRESSSCOPE® Monitor LCD when you press OK.
Four lines appear at a time.
Figure 4-4
shows the main menu in two parts:
Figure 4-4 EXPRESSSCOPE® Monitor Main Menu
Press the navigation buttons (up or down arrows on the EXPRESSSCOPE® Monitor;
refer to
Figure 4-1
) to move the right arrowhead ( ) to the desired option, and then press
OK
to select the option.
4.2.3. EXPRESSSCOPE® Monitor LCD Timeouts
If the EXPRESSSCOPE® Monitor is left idle, the main menu times out and the LCD
again displays the main screen (refer to
Figure 4-2
). If the EXPRESSSCOPE® Monitor
is left idle longer, the back light turns off.
Press OK to activate the menu system and display the main screen.
4.2.4. Navigating Menus
The system, partition, and cell menus offer more detail and command entry. For
example, if you navigate to System on the main menu (refer to
Figure 4-4
) and press OK,
the system menu appears, as shown in
Figure 4-5
.
