2-1
Section 2
Overview of System Interfaces
The Express5800/A1160 system offers a number of user interfaces for different
purposes. This section contains the following information for each interface:
• A summary of the interface capabilities
• Uses for the interface
• Instructions for accessing and logging on, if appropriate
• Pointers to additional information in this and other documents
2.1. Remote console interfaces
Management firmware is a comprehensive means of configuring, controlling, and
monitoring individual components of the Express5800/A1160 system and the system as
a whole. Management firmware runs on the Service Processor.
The remote console interfaces are client user interfaces to management firmware that
are provided by Web servers running on Service Processors. You can access remote
console interfaces using a Web browser on any device that is connected to the LAN that
supports the Express5800/A1160 system.
Different remote console interfaces (sets of Web pages) control each partition, each cell,
and the system as a whole. Each remote console interface provides commands to view
information and update settings for that component.
Figure 3-2 , Figure 3-24 and Figure
3-27 show the opening page of each set of Web pages.
For more information, refer to
• The following paragraphs for uses of and logging on to the remote console
interfaces
• Section 3 Remote console interfaces for detailed information about the sets of Web
pages for partitions, cells, and the system, including the available commands
• The
Console Manager Help for a description of Console Manager, the workstation
requirements for both the Partition Desktop and JViewer interfaces, and Partition
Desktop menus and buttons
Note: Console Manager Help is available through the Partition Desktop and from
the Product Support Web Site. The JViewer Help is available through JViewer.
• Later portions of this guide for procedures that use remote console interfaces
