Configuring Alerts using Server Management Software
7-7
10. Select the alert destination and click Send Test Alert to check the validity of the
configured destination.
7.2.3. Clearing Alert Destinations using remote console interface
If you no longer want to send alerts to a configured destination, you can clear the
destination, as follows:
1. Navigate to the alert management page on the remote console interface for the
partition, as shown in Figure 3-12 .
2. Select an existing alert destination that you want to clear.
3. Click Clear Entry to clear an alert destination.
A confirmation dialog box appears.
Alternatively, click Cancel to return to the Alert Management page without clearing
the alert definition and skip the rest of this procedure.
4. Click
OK
.
The Alert Management page appears with the destination cleared.
7.3. Configuring Alerts using Server Management
Software
Server Management software enables you to manage reports of events. ESMPRO Alert
Manager directs and manages reports of events through SNMP traps supplied by
ESMPRO Agents installed on partitions. You can configure alert notifications to be
reported in any of the following forms:
• Alert log displayed in the AlertViewer window (refer to 9.4.1 Viewing Alerts using
ESMPRO Manager AlertViewer )
• Internet mail (requires the IP address or name of the SMTP mail server)
• Pop-up message on screen
• Printer output
• Text file
• Command for execution
You must configure the reporting functions using ESMPRO Alert Manager on the
management server and ESMPRO Agent for Windows or ESMPRO Agent for Linux on
the partitions. If you configure Internet mail alert notifications, you must configure the IP
address or name of the SMTP server. The following subsections provide procedures to
configure alerts in Server Management software.
