Examine the Cell EXPRESSSCOPE® Monitor LCDs
10-22
displayed on the EXPRESSSCOPE® Monitor LCD, and whether the unit is a CRU or a
FRU.
Table 10-1 Device Names on the EXPRESSSCOPE® Monitor LCD
Full name EXPRESSSCOPE®
Monitor LCD Name Additional Display
Details
Unit Type
(FRU/CRU)
EXPRESSSCOPE®
Monitor Control_Panel FRU
Fan module Fan_Modx x=
0 (left module)
1 (right module)
CRU
Interconnect cable Intercon_Cablex x=
0 (right)
1 (middle)
2 (left)
FRU
I/O riser board IOR_Brd FRU
PCI expansion card IO_Slotx_y_z x=cell card slot 0 through
5
y=expansion rack 1 or 2
z=expansion rack slot 1
through 5
CRU
Voltage regulator module IPVRMx x=0,1,2,or 3 FRU
Main logic module MainLogic_Module FRU
Memory board Mem_Brdx x=
0 (left board)
1 (right board)
CRU
DIMM Mem_Brdx_DIMMyy x=
0 (left board)
1 (right board)
yy=0 through 15
CRU
Management board Mgmt_brd FRU
PCIe card PCIe_Slotx x=0 (bottom) through 5
(top) CRU
RAID controller PCIe_Slot6 FRU
Power supply PwrSupplyx x=
0 (left power supply)
1 (right power supply)
CRU
Drive tray n/a FRU
DVD drive n/a CRU
Hard drove n/a CRU
PCIe carrier n/a CRU
