Network
4-17
a. If the value of Set DHCP on the network menu is On, navigate to Set DHCP
and press OK.
The value changes to Off.
b. Navigate to Set IP Addr and press OK.
The Set IP Addr screen appears.
c. Follow the instructions in 4.5.3 Updating Network Values to set the value
appropriately.
6. Navigate to Commit Changes on the network menu, and press OK.
The EXPRESSSCOPE® Monitor LCD displays a message to confirm the
commitment.
7. Press OK.
The changes are committed and the setting reservation is released.
4.5.3. Updating Network Values
When you submit a command to update a network value, the current value appears on
the EXPRESSSCOPE® Monitor LCD with a blinking cursor under one digit (refer to
Figure 4-14 ).
Figure 4-14 Setting IP Address Value
1. Use the left and right navigation arrows to move the cursor to the desired digit.
2. Use the up and down navigation arrows to adjust the value under the cursor, where
the following behavior applies:
• Roll-up and roll-down actions (that is, increasing or decreasing the values)
have intelligent behavior. For example
- If the current value is 168 and the cursor is on the rightmost digit (8) when
you press the up arrow, the value 168 rolls up to 169.
- 169 rolls up intelligently to 170, not 160.
- 170 rolls down intelligently to 169, not 179.
• You can change octet values (group of three digits) easily by moving the cursor
