Components on the Rear of a Cell
11-7
Table 11-2 Components on the Front of the Cell
Component Description
Fan module Provides the airflow needed to cool the cell.
LED fan status indicators Provide fan status with one LED light on each
fan module. A green light indicates normal
operations.
Drive tray Provides slots for up to six 2.5-inch SAS hard
drives.
Hard drives Six 2.5-inch SAS hard drives enclosed in
individual drive carriers.
EXPRESSSCOPE® Monitor A control and display interface for the cell and
the partition containing the cell.
LCD Displays status information and provides a
menu of management tasks for the cell on a
4-line by 20-character liquid crystal display
(LCD) panel. Refer to the User’s Guide for
information on using the LCD.
Power button Turns on or off power for the cell.
ID button Turns on a blue LED in the back of the cell for
identification purposes during servicing. A
button on the back of the cell turns off the LED.
Navigation buttons Enables the selection of EXPRESSSCOPE®
Monitor menu options.
LED status indicators Provides status for the cell. The top light
indicates power status. The bottom light
indicates cell status. See the
EXPRESSSCOPE® Monitor LCD or the
remote console interface for additional
information on the power or cell status.
DVD-RW drive A DVD-RW drive for your use.
Partition USB connections Provides two universal serial bus (USB) 2.0
ports.
11.7. Components on the Rear of a Cell
Figure 11-6 identifies the components that are visible on the rear of the cell. Table 11-3
describes these components in more detail.
