92
(4) Position
When the "Channel ON/OFF" function is set,
select the channel position from "Audio In,"
"CobraNet In," "Audio Bus," "Ext. In," "CobraNet
Bus," "Audio Out," or "CobraNet Out."
When the "Line Input" function is set, select the
slot in which the D-936R or D-937SP module has
been installed.
When the "Console Switch" function is set, select
the ID number for the D-2012C to be controlled.
(5) Channel/Contact
When the "Channel On/Off" function is set, select
the channel.
When the "Console Switch" function is set, select
the function key number for the D-2012C to be
set.
Contact output function assignment: Memory
Assign any desired preset memory number (1 – 32) recall interlocking output (tally) to the terminal.
Step 1. Click each terminal's Function button to select "Memory" from the pull-down menu.
Step 2. Click the Parameter button to select the preset memory number from the pull-down menu.
