36
6.5.2. When the D-2012C is selected
When in online mode, all level meters for fader layer channels (see p. 122 ) selected at the D-2012C are
simultaneously displayed.
[Level monitor view]
(1)
(2)
(3)
(1) Level meter
(2) Motorized fader/rotary encoder number display
(3) Fader layer display tab
Displays the currently selected fader layer.
Note
Layers cannot be switched through operation of this screen.
6.6. All Mute View
In this view, all the output channels in the system can be muted simultaneously.
The All Mute view is active only when online, and its status cannot be stored in a file.
The display can be switched between showing and hiding views from [View
All Mute View Show/Hide]
on the menu.
The All Mute function can be turned on or off from [View
All Mute View All Mute] on the menu.
All Mute: ON
All the outputs of all units are muted.
All Mute: OFF
Each output is subject to its mute setting, which can be confirmed on the Mute
view (see
p. 83 ).
