Toa D-2000 Series - Manual (Page 83)

83
All Mute function is ON.
Only in this case, no output is muted.
Mute function for each individual output is ON.
Mute function for each individual output is OFF.
All Mute function is OFF.
7.3.12. Mute view
Clicking the Mute box in the output flow view displays the Mute view in the Contents view (located beneath the
Output flow view).
The Mute box cannot be stereo-linked.
The Mute view shows the "All Mute" state when this function is on.
[Mute box]
The Mute box turns into different icons as shown below depending on the Mute function ON/OFF and All Mute
function ON/OFF.
[Mute view]
(1)
(1) Mute ON/OFF button
Displays the Mute ON or OFF state on it.
Double-clicking the button switches the Mute state for each output between ON and OFF.
