118
Step 3. Select the unit ID.
Step 4. Select the channel area.
Step 5. Select the channel number.
Note
The same channel cannot be assigned to multiple motorized faders and rotary encoders in a single
fader layer.
Step 6. Select the level meter position.
Selecting the channel area and level meter position determines the level area (see p. 33 ).
Step 7. Select the fader knob color. (Layer 1 only)
The fader color is common to the four fader layers.
Step 8. Click the OK button.
Step 9. Repeat these steps only for all motorized faders and encoders, and perform similar settings for other
layers as well.
3
4
5
6
7
8
Step 2. Click the SEL/MONI button for the motorized fader or rotary encoder to be set.
The Console Channel Setting screen is displayed.
(Example) Level area: Audio In (PFL)
Channel area Level meter position
