Page 88
88
Rockwell Automation Publication 7000-UM151E-EN-P - January 2013
Chapter 3 Component Definition and Maintenance
DC Link and Fan Cabinet
Components
This section describes the DC link and fan cabinet components of your
PowerFlex 7000 “B” Frame drive. It also details a number of regular or recurring
maintenance tasks that will keep your drive in peak operating condition.
For control and cabling cabinets, see
Control / Cabling Cabinet Components on
.
For converter cabinets, see
Converter Cabinet Components on page 45
.
