Rockwell Automation Publication 7000-UM151E-EN-P - January 2013 239
Drive Programming and Parameters Chapter 5
The following memory cards from Rockwell Automation employ these chips:
• 2711-NM11
• 2711-NM12
• 2711-NM14
• 2711-NM24
• 2711-NM28
• 2711-NM216
Transferring information between these two forms of flash memory and the drive
may require you to:
• format a flash card
• open the file directory on a flash card containing the DOS file format
• select and load a program (firmware) from the flashcard to the operator
interface.
• save the parameters from the drive on the flash card or in the operator
interface
• download parameters to the drive from a flash card or previously-saved in
the operator interface
• load a language module from the flash card.
Access the Transfer operations from the UTILTY screen by pressing [F7] from
the top-level menu.
Figure 230 - Transfer Main Menu
You can access additional flash memory or transfer functionality from this screen.
IMPORTANT To edit ANY option, you must have an access level above 'Monitor'. Press
[F8] and enter the appropriate PIN to access and modify drive
parameters. Refer to
Configuring Access Levels on page 210 for more
information on access security.
