Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control (PanelView 550) User Manual
Page 70
70
Rockwell Automation Publication 7000-UM151E-EN-P - January 2013
Chapter 3 Component Definition and Maintenance
3. Detach the leads located on the bottom of the resistor assembly.
Figure 46 - PowerCage removal (SGCT Type PowerCage)
Figure 47 - PowerCage removal (heatpipe PowerCage)
Snubber Capacitor
Sharing Resistor Connection
Snubber Resistor Connection
Common Snubber and
Sharing Resistor Connection
Anode Connection
Cathode Connection
Push Nuts
Push Nuts
Snubber Capacitor
Sharing Resistor Connection
Snubber Resistor Connection
Common Snubber and
Sharing Resistor Connection
Anode Connection
Cathode Connection
Snubber Capacitor
Sharing Resistor Connection
Snubber Resistor Connection
Common Snubber and
Sharing Resistor Connection
Anode Connection
Cathode Connection
Push Nuts
Push Nuts
REMOVE
HARDWARE
MAKE VERTICAL CUT ON GASKET AT THESE
TWO LOCATIONS BETWEEN RESISTOR CAGE
AND THE MAIN POWERCAGE
