200 Rockwell Automation Publication 7000-UM151E-EN-P - January 2013
Chapter 4 Initial Operator Interface Configuration
To change a meter, press
▲
or
▼
to select a meter and press [Enter]. To modify
the text, press
►
. If nothing happens, you do not have access to this feature. Refer
to Configuring Access Levels on page 210 .Correct the access issues, and press
[F8] to continue on this screen.
The cursor highlights the first character position of the string as shown in
Figure 172 . Refer to the section entitled “Edit Text”.
Figure 172 - Editing text
When editing is complete, the screen will appear as in Figure 173 .
Figure 173 - Editing complete
The operator interface contains a default set of meters. Select the default set by
pressing [F2] from the 'Meters' screen to view default text and tags as shown in
Figure 170 on page 199 .
Edits do not take affect until you press [F10] and exit the screen. Cancel any edits
prior to exiting the screen by pressing [F7].
