3300/4160v with afe rectifier – Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control (PanelView 550) User Manual
Page 19
Rockwell Automation Publication 7000-UM151E-EN-P - January 2013
19
PowerFlex 7000 Overview Chapter 2
3300/4160V with AFE Rectifier
Figure 5 - 3300/4160 Volt – AFE Rectifier, Configuration #1 – Direct-to-Drive
Figure 6 - 3300/4160 Volt – AFE Rectifier, Configuration #2 – Separate Isolation
Transformer
SGCTs
LINE CONVERTER
DC LINK
L+
M+
SGCTs
MACHINE CONVERTER
U (T1)
V (T2)
W (T3)
L-
M-
LR
L1
L2
L3
OPTIONAL INPUT STARTER
SGCTs
LINE CONVERTER
DC LINK
L+
M+
SGCTs
MACHINE CONVERTER
U (T1)
V (T2)
W (T3)
L-
M-
REMOTE
ISTX
2U (X1)
2V (X2)
2W (X3)
1U
1V
1W
