Line & Load Cable Sizes Appendix B
Max. Load Cable Sizes
PRODUCT OUTPUT (MOTOR SIDE)
Bulletin Description (V/
Freq./Rect.)
Drive
rating
(A)
Drive Structure Code Drive Enclosure
Opening
Inches (mm) 1
Max. Size & No.
Incoming Cables:
NEMA
2-4-5-6-8-9
Max. Size & No.
Incoming Cables:
IEC
2-4-5-6-8-9
Vertical Space
Avail. for Stress
Cones Inches
(mm)
‘B’ Frame
(Air-
Cooled)
PF7000 2400V/60Hz/RPDTD 46-430 70.40, 70.41, 70.44,
70.45
9.79x10.97 (249x279) 1 (2) 500MCM 5kV
or 8kV/phase
(2) 253mm² 5kV
or 8kV/phase
28.5 (725)
PF7000 2400V/60Hz/RPDTD 46-375 70.40C, 70.41C, 70.44C
w/close-coupled starter
6.52x9.88 (168x251) (1) 500MCM 5kV
or 8kV/phase OR
(2) 250MCM 5kV
or 8kV/phase
(1) 253mm² 5kV
or 8kV/phase OR
(2) 127mm
2 5kV
or 8kV/phase
16.2 (411)
PF7000 3300V/50Hz/RPDTD 46-430 70.43, 70.44, 70.45,
70.47
9.79x10.97 (249x279) 1 (2) 500MCM 5kV
or 8kV/phase
(2) 253mm² 5kV
or 8kV/phase
28.5 (725)
PF7000 3300V/50Hz/RPDTD 46-375 70.43C, 70.44C, 70.45C,
70.47C w/close-coupled
starter
5.61x7.19 (142x183) (1) 500MCM 5kV
or 8kV/phase OR
(2) 250MCM 5kV
or 8kV/phase
(1) 253mm² 5kV
or 8kV/phase OR
(2) 127mm
2 5kV
or 8kV/phase
16.2 (411)
PF7000 4160V/50Hz/RPDTD 46-375 70.43, 70.44, 70.45,
70.47
9.79x10.97 (249x279) 1 (2) 500MCM 5kV
or 8kV/phase
(2) 253mm² 5kV
or 8kV/phase
28.5 (725)
PF7000 4160V/50Hz/RPDTD 46-375 70.43C, 70.44C, 70.45C,
70.47C w/close-coupled
starter
5.61x7.19 (142x183) (1) 500MCM 5kV
or 8kV/phase OR
(2) 250MCM 5kV
or 8kV/phase
(1) 253mm² 5kV
or 8kV/phase OR
(2) 127mm
2 5kV
or 8kV/phase
16.2 (411)
PF7000 4160V/60Hz/RPDTD 46-430 70.43, 70.44, 70.45,
70.47
9.79x10.97 (249x279) 1 (2) 500MCM 5kV
or 8kV/phase
(2) 253mm² 8kV
or 15kV/phase
28.5 (725)
PF7000 4160V/60Hz/RPDTD 46-375 70.43C, 70.44C, 70.45C,
70.47C w/close-coupled
starter
5.61x7.19 (142x183) (1) 500MCM 5kV
or 8kV/phase OR
(2) 250MCM 5kV
or 8kV/phase
(1) 253mm² 5kV
or 8kV/phase OR
(2) 127mm
2 5kV
or 8kV/phase
16.2 (411)
PF7000 6600V/50Hz/RPDTD 46-285 70.46, 70.47, 70.48,
70.49
9.79x10.97 (249x279) 1 (1) 500MCM
8kV/phase
(1) 253mm² 5kV
or 8kV/phase
28.5 (725)
PF7000 6600V/50Hz/RPDTD 40-285 70.46C, 70.47C, 70.49C
w/close-coupled starter
5.61x7.19 (142x183) (1) 500MCM 5kV
OR
(2) 250MCM 8kV
or 15kV/phase
(1) 253mm² OR
(2) 127mm
2 8kV
or 15kV/phase
16.2 (411)
PF7000 6600V/60Hz/RPDTD 40-285 70.46, 70.47, 70.48,
70.49
9.79x10.97 (249x279) 1 (2) 500MCM 8kV
or 15kV/phase
(2) 253mm² 5kV
or 8kV/phase
28.5 (725)
PF7000 6600V/60Hz/RPDTD 40-285 70.46C, 70.47C, 70.49C
w/close-coupled starter
5.61x7.19 (142x183) (1) 500MCM 5kV
OR
(2) 250MCM 8kV
or 15kV/phase
(1) 253mm² OR
(2) 127mm
2 8kV
or 15kV/phase
16.2 (411)
PF7000 2400V/60Hz/RPTX 46-430 70.1, 70.2, 70.25, 70.26 9.79x10.97 (249x279) 1 (2) 500MCM 5kV
or 8kV/phase
(2) 253mm² 5kV
or 8kV/phase
28.5 (725)
PF7000 3300V/50Hz/RPTX 46-430 70.10, 70.27, 70.28,
70.30
9.79x10.97 (249x279) 1 (2) 500MCM 8kV
or 15kV/phase
(2) 253mm² 5kV
or 8kV/phase
28.5 (725)
PF7000 4160V/50Hz/RPTX 46-430 70.10, 70.27, 70.29,
70.30
9.79x10.97 (249x279) 1 (2) 500MCM 8kV
or 15kV/phase
(2) 253mm² 5kV
or 8kV/phase
28.5 (725)
PF7000 4160V/60Hz/RPTX 46-430 70.2, 70.26, 70.27, 70.28,
70.29, 70.31
9.79x10.97 (249x279) 1 (2) 500MCM 5kV
or 8kV/phase
(2) 253mm² 5kV
or 8kV/phase
28.5 (725)
PF7000 6600V/50Hz/RPTX 40-285 70.11, 70.28, 70.30,
70.31
9.79x10.97 (249x279) 1 (2) 250MCM 8kV
or 15kV/phase
(2) 253mm² 8kV
or 15kV/phase
28.5 (725)
