Drive Programming and Parameters Chapter 5

View a Directory

View the card directory by pressing [F7] on the TRANSFER screen. The
directory shows the filename and extension, along with the file creation date and
time stamp.

Figure 232 - Flash card directory

When you view the directory from the TRANSFER screen, at the listing includes
all files on the flash card. When you view the directory from another operations
screens, only the files that are relevant to the current operation are visible.

Only the card’s root directory is visible, as the operator interface does not support
sub-directories.

Select/Enter a Filename

From the DIRECTORY screen is entered, use

▲

▼

to select a file and press

[Enter] to proceed with the operation.

Figure 233 - Typical File Selection

Press [F10] to abort the selection and return to the previous screen.
