Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control (PanelView 550) User Manual
Page 46
46
Rockwell Automation Publication 7000-UM151E-EN-P - January 2013
Chapter 3 Component Definition and Maintenance
Figure 26 - Converter cabinet (standard model, 2400V)
Differential
Pressure Sensor
Inverter Modules
Rectifier Modules
Isolated Gate Driver
Power Supplies (IGDPS)
Ground Bus
Temperature Feedback
Board (Inverter)
Temperature Feedback
Board (Rectifier)
