Low voltage control section – Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control (PanelView 550) User Manual
Page 112
112
Rockwell Automation Publication 7000-UM151E-EN-P - January 2013
Chapter 3 Component Definition and Maintenance
Low Voltage Control
Section
The low voltage control section houses all of the control circuit boards, relays,
Operator Interface Terminal, DC/DC power supply, and most other low voltage
control components. Refer to
for a generic representation of a low
voltage tub arrangement.
Figure 86 - Low voltage tub compartment
Optical
Interface
Boards
DC/DC
Power
Supply
Analog
Control
Board
Tach Feedback
Circuit Board
Drive Processor
Module (DPM)
ANALOG
CONTROL
BOARD
