Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control (PanelView 550) User Manual
Page 71
Rockwell Automation Publication 7000-UM151E-EN-P - January 2013
71
Component Definition and Maintenance Chapter 3
4. Remove the push nuts on the end of the retaining rod. Pinch the clip
together and pull off. Pull out the retaining rod.
Figure 48 - Snubber and Sharing Resister replacement (standard model)
Retaining Rod
Detach the leads
of the resistor assembly
Retaining Rod
Detach the leads
of the resistor assembly
Pinch and remove clips at ends of retaining rods
Extract
retaining rod
Pinch and remove clips at ends of retaining rods
Extract
retaining rod
