Appendix
E
Specifications
“B” Frame Drive
Specifications
ATTENTION: In the event of discrepancies between information
published in generic manual specifications and those included with your
specific design or electrical drawings, take the DD or EE ratings as correct
values.
Description Specifications
Control Power 220/240 V or 110/120 V, 1 phase – 50/60 Hz (20 Amp)
External I/O 16 Digital Inputs, 16 Digital Outputs
External Input Ratings
50/60 Hz AC or DC
120-240 V – 1 mA
External Output Ratings
50-60 Hz AC or DC
30-260 V – 1 amp
Analog Inputs (3) Isolated, 4-20mA or 0-10 V
Analog Resolution
• Analog input 12 Bit (4-20 mA)
• Analog input 13 Bit (0-10V)
Analog Outputs
• (1) Isolated, 4-20 mA
• (8) Non-isolated, 0-10 V
Communication Interface DPI
Scan Time Internal DPI – 2 ms min., 4 ms max.
Communications Protocols
(Optional)
R I/O Lon Works
DeviceNet Can Open
Ethernet RS485 HVAC
Profibus RS485 DF1
Modbus RS232 DF1
Interbus USB
Enclosure NEMA 1 (IP21), NEMA 12 (IP42)
Lifting Device Standard / Removable
Mounting Arrangement Mounting Sill Channels
Structure Finish
Epoxy Powder – Paint
Exterior Sandtex Light Grey (RAL 7038) – Black (RAL 8022)
Internal – Control Sub Plates – High Gloss White (RAL 9003)
Interlocking Key provision for customer input Disconnecting Device
Corrosion Protection Unpainted Parts (Zinc Plates / Bronze Chromate)
Fiber Optic Interface Rectifier – Inverter – Cabinet (Warning/Trip)
Door Filter Painted Diffuser with Matted Filter Media
Door Filter Blockage Air Flow Restriction Trip/Warning
Ambient Temperature
0°C to 40°C (32°F to 104°F)
0°C to 50°C (32°F to 122°F) - Optional
Storage and Transportation
Temperature Range
-40°C to 70°C (-40°F to 185°F)
Relative Humidity 95% Non-Condensing
Altitude (Standard) 0 to 3300 ft. (0 to 1000 m)
Altitude (Optional) 0 to 16400 ft. (1001 to 5000 m)
Seismic (UBC Rating) 1, 2, 3, 4
Standards NEMA, IEC, CSA, UL, ANSI, IEEE
