210 Rockwell Automation Publication 7000-UM151E-EN-P - January 2013
Chapter 5 Drive Programming and Parameters
Regardless of the method used for configuration, the default factory parameters
are available from the Drive Identity Module (DIM). The DIM enables Rockwell
Automation to customize each drive at the factory for the intended application,
using all known information at the time of building the drive.
Configuring Access Levels
The drive uses PIN-protected access levels to limit the risk of unauthorized
changes. PINs consist of a number between 0 and 65535. Each access level, except
for the first one, 'Monitor', has its own PIN. PIN values can be unique, or you can
set them all to the same value.
The 'Monitor' level does not have an associated PIN. With this access level, users
can view the drive configuration but not change it. In addition to providing
protection, access levels also filter viewable information for each level. On any
level other than 'Monitor', viewable information is configurable.
Figure 184 - Access screen
The access screen ( Figure 184 ) is accessible from anywhere the access level affects
user operations, including:
• [F10] on the top level menu
• [F8] on the MODIFY PARAMETER screen
• [F8] key on the SETUP screen
• [F8] key on the TRANSFER Screen
• [F8] key on the DIAGNOSTIC SETUP screen
