Appendix E Specifications
Description
Specifications
NEMA:
200 to 5,500 hp
Power Rating (Air Cooled)
IEC: 150
to
4,100
kW
Motor Type
Induction or Synchronous
Input Voltage Rating
2400V, 3300V, 4160V, 6600V
Input Voltage Tolerance
± 10% of Nominal
Voltage Sag
%
0
3
-
Control Power Loss Ride-Through
5 Cycles (Std)
Input Protection
Metal Oxide Varistor (MOV) – 6P/18P
Surge Arrestors (AFE/D2D)
Input Frequency
50/60 Hz, +/- 5%
Power Bus Short-circuit Current Withstand
5 Cycle
3300 V – 6000 V
M
Y
S
S
M
R
A
k
5
2
Basic Impulse Level
)
m
0
0
0
1
–
0
(
V
k
0
5
Power Bus Design
Copper – Tin plated
Ground Bus
Copper – Tin plated 6 x 51 mm (¼ x 2 in.)
Customer Control Wireway
Separate and Isolated
Input Power Circuit Protection
Vacuum Contactor with Fused Isolating Switch
Input Impedance Device
Isolation Transformer or AC Line Reactor
Output Voltage
0 – 2300 V
0 – 3300 V
0 – 4160 V
0 – 6600 V
Inverter Design
PWM
Inverter Switch
Symmetrical Gate Commutated Thyristor (SGCT)
Inverter Switch Failure Mode
Non-rupture, Non-arc
Inverter Switch Failure Rate (FIT)
100 per 1 Billion Hours Operation
Inverter Switch Cooling
Double Sided, Low Thermal Stress
Inverter Switching Frequency
420-540 Hz
Voltage
SGCTs (per phase)
Number of Inverter SGCTs
2400 V
3300 V
4160 V
6600 V
2
4
4
6
Voltage
PIV
SGCT PIV Rating
(Peak Inverse Voltage)
2400 V
3300 V
4160 V
6600 V
6500 V
6500 V
6500 V
6500 V
Rectifier Designs
AFE (Active Front End), 6 Pulse, 18 Pulse
Direct-to-Drive
Rectifier Switch
SCR (6 Pulse, 18 Pulse)
SGCT (AFE, Direct-to-Drive)
Rectifier Switch Failure Mode
Non-rupture, Non-arc
Rectifier Switch Failure Rate (FIT)
50 (SCR) 100 (SGCT) per 1 Billion Hours Operation
Rectifier Switch Cooling
Double Sided, Low Thermal Stress
Voltage Sag tolerance is reduced to -25% when control power is supplied from medium voltage via CPT.
MOVs are used for 6 Pulse/18 Pulse. Surge Arrestors are used for AFE/D2D configurations.
Short-circuit fault rating based on input protection device (contactor or circuit breaker).
BIL rating based on altitudes < 1000 m (3,300 ft.) Refer to factory for derating on altitudes >1000 m.
Optional
