Rockwell Automation Publication 7000-UM151E-EN-P - January 2013 209
Drive Programming and Parameters Chapter 5
There are four character sets. Press [F3] to cycle through each of the following:
• the upper case letters A-Z.
• the lower case letters a-z.
• the numbers 0-9 and the characters '.' and '-'.
• the characters: space _ () [ ] {} < > | @ # $ % & *! ^ + = ; : ?
A special set consisting of A-Z, 0-9, and the underscore character, is available for
filenames. You cannot selected this set via [F3] or modified it by pressing [F5].
To change case on a letter in the edit field, press [F5].
To delete the entire string (i.e. fill it with spaces), press [F4].
To abort the text edit, press [Backspace] to restore the string to its original
contents.
Press [Enter] to complete the text entry. Changes are permanent only after you
press [F10] to exit the screen.
Configure the Drive
Configuring the drive motor and application involves defining a number of
operational parameters within the drive via the operator interface, including:
• changing a parameter setting.
• assigning a parameter to an analog port.
• enabling or disabling (“masking’) selected faults.
• defining custom faults attached to external inputs.
• configuring the XIO.
• defining data sent to an optional PLC connection.
• saving and restoring drive settings.
• selecting an alternate language (if previously loaded in operator interface).
There are two methods for configuring the drive. This section describes the more
complete method to configure the drive for any application. You may also
configure the majority of drive applications using the Setup Wizard, accessible
from the SETUP screen by selecting 'Setup Wizard' from the options list and
pressing [Enter].
IMPORTANT Character sets may vary depending on the drive’s default language
option.
IMPORTANT Character sets may only be valid for the currently-selected language. Any
characters for a selected language other than the four sets defined
above, will only display properly in the selected language. Other
languages may not contain the appropriate display characters.
