6600 v with afe rectifier – Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control (PanelView 550) User Manual
Page 20
20
Rockwell Automation Publication 7000-UM151E-EN-P - January 2013
Chapter 2 PowerFlex 7000 Overview
6600 V with AFE Rectifier
Figure 7 - 6600 Volt – AFE Rectifier, Configuration #1 – Direct-to-Drive
Figure 8 - 6600 Volt – AFE Rectifier, Configuration #2 – Separate Isolation
Transformer
SGCTs
LINE CONVERTER
DC LINK
L+
M+
SGCTs
MACHINE CONVERTER
U (T1)
V (T2)
W (T3)
L-
M-
LR
L1
L2
L3
OPTIONAL INPUT STARTER
SGCTs
LINE CONVERTER
DC LINK
L+
M+
SGCTs
MACHINE CONVERTER
U (T1)
V (T2)
W (T3)
L-
M-
REMOTE
ISTX
2U (X1)
2V (X2)
2W (X3)
1U
1V
1W
