Chapter 19 Filters 794
This filter causes rasterization in 3D groups. For more information on rasterization, see Groups
and rasterization on page 1045.
Original image Scrape filter applied
Parameters in the Inspector
•
Center: Sets the position of the center of the scrape. Drag the Center onscreen control to
adjust its value in the Canvas.
•
Rotation: Sets the angle of rotation of the scrape. Drag the outer handle of the onscreen
control to adjust the Rotation value in the Canvas.
•
Amount: Sets the ramping of the number of pixels spread across the range of the scrape.
Values range from 0 (very gradual) to 200 (hard edge).
•
Mix: Sets the percentage of the original image to be blended with the distorted image.
•
Publish OSC: Publishes the filter’s onscreen controls in Final Cut Pro X. For more information on
creating content for use in Final Cut Pro, see
Final Cut Pro X templates overview on page 385.
Sphere
Simulates the effect of an image wrapped around a sphere. This filter can be used to turn an
image of a map into an imprecise globe.
This filter causes rasterization in 3D groups. For more information on rasterization, see Groups
and rasterization on page 1045.
Original image Sphere filter applied
Parameters in the Inspector
•
Center: Sets the position of the center of the sphere. Drag the Center onscreen control to
adjust its value in the Canvas.
•
Radius: Sets the radius of the sphere.
•
Crop: Sets whether the object is cropped at its original boundaries.
•
Mix: Sets the percentage of the original image to be blended with the distorted image.
