1.2 Checking the product
Prior to the use, check the following.
★ Checking the model
The model number is printed on the box and side of the product. Check that the numbers thereon
matches with the model that had been ordered.
★ Appearance
Check that no scratch or damage is present on the case, front panel or terminal block.
★ Check that accessories are included in the box. (See below for the list of the accessories.)
Mounting tool, brief operation manual and rubber packing (attached to the main frame)
1.3 Model table
TTM

20
       
① ② ③④ ⑤⑥⑦⑧⑨⑩ ⑪
Symbol Item Description Remarks
①
Size
4 48 x 48
5 96 x 48
7 72 x 72
9 96 x 96
②
Color
Q Color of case: Black
X Color of case: Gray Not available for 205,7,9.
③
Output 1
N None J Voltage 0 - 5 VDC
R Relay F Voltage 1 - 5 VDC
P SSR drive voltage G Voltage 0 - 10 VDC
A Open collector I Current 4 - 20 mADC
K Voltage 0 - 1 VDC H Voltage 0 - 10 mVDC
④
Output 2
N None J Voltage 0 - 5 VDC
R Relay F Voltage 1 - 5 VDC
P SSR drive voltage G Voltage 0 - 10 VDC
A Open collector I Current 4 - 20 mADC
K Voltage 0 - 1 VDC H Voltage 0 - 10 mVDC
⑤ Outputs 3
and 4
A Open collector Common
R Relay contact Common
⑥ Outputs 5
and 6
A Open collector Not available for 204. *1
R Relay contact Not available for 204. *1
⑦
Output 7
A Open collector Not available for 204. *3
R Relay contact (common independent) Not available for 204. *3
⑧
AI input Y Remote SV input: Only voltage and current Not available for 204.
⑨
Option
Case of TTM-204,207
ST CT 1,2input *2
SV CT 1 input, Event 2 input *2
UV Event 1,2 input
STW CT 1,2input, Event 3 input Not available for 204.*2,*3
SVW CT 1 input, Event 2,3 input Not available for 204.*2,*3
UVW Event 1,2,3 input Not available for 204. *3
Case of TTM-205,209
ST CT 1,2input *2
SV CT 1 input, Event 2 input *2
UV Event 1,2 input
SVW CT 1 input, Event 2,3,4 input *2
UVW Event 1,2,3,4 input
STUV CT 1,2 input, Event 1,2 input *2
STUVW CT 1,2 input, Event 1,2,3,4 input *2
⑩
M Communication (RS-485)
⑪ 24 V power
supply
Free power supply
L 24 VAC / 24 VDC
For models 205,207,209 are still under
development.
*1 Output6 is not selectable for 207
*2 CT is not selectable, if there are only analogue output.
*3 Either W (only event3) or output7 should be selected for 207.
When the option from ④ is not added, the model code is omitted. Example. TTM-205-Q-RN-M
