TTM-207
Output 1
Output 2
Outputs 3 and 4
Output 5
Relay
Output 7
SSR/current/voltage/
open collector
Relay
SSR/current/voltage/
open collector
Relay
Open collector
Relay
Open collector
* Outputs 3 and 4 are for common shared
Relay
Open collector
