Page 44

48-7009-E
4-3
■ Initial screen
The input type number is displayed right after the power turns on, and in 4 seconds, the run mode screen is
displayed.
Initial screen
Parameter for input display
Input type No.
(“0” is set at factory shipment.)
4 seconds
0
INP1
0
25
Constant value run
PV value (present value)
SV value (target value)
Power-on
At SET 21 program mode setting
A (C/P
0) program run mode is established.
Initial screen
Parameter for input display
Input type No.
(“0” is set at factory shipment.)
4 seconds
0
INP1
Program run mode screen
PV value (present value)
SV value (PROG)
Power-on
PROG
25
Input type No. and input type
No.
Input type
0
K thermocouple
1
J thermocouple
2
T thermocouple
3
E thermocouple
4
R thermocouple
5
S thermocouple
6
B thermocouple
7
N thermocouple
8
U thermocouple
9
L thermocouple
10
WRe5-26 thermocouple
11
PR40-20 thermocouple
12
PLII thermocouple
13
Pt100
14
JPt100
15
0 - 10 mVDC
16
0 - 1 VDC
17
0 - 5 VDC
18
1 - 5 VDC
19
0 - 10 VDC
20
4 - 20 mADC
