■ CT 2 target connection setting
SEt12
CT
Setting content Initial value
1 CI2
1 Connected to OUT 1 (settable when D0)
1
2 Connected to OUT 2 (settable when D0)
3 Connected to OUT 3 (settable when an option existent)
4 Connected to OUT 4 (settable when an option existent)
5 Connected to OUT 5 (settable when an option existent)
6 Connected to OUT 6 (settable when an option existent)
7 Connected to OUT 7 (settable when an option existent)
Set the output measured by CT 2.
Note An analog output cannot be set for the target connection.
In case the Even Output is needed, please refer to P6 – 51 Event Function 3 Setting (CT abnormal).
In case of changing the display color due to CT abnormality, please refer to P6 – 66CT Display color During the CT
Abnormality.
Note At-abnormality display color does not change unless the event function 3 setting (CT abnormality) is set.
Note Take care that the product does not properly operate when the subject of control is connected to an output that is set for the CT
abnormality event.
■ CT 2 current value monitor
SEt12
CT
Setting content Initial value
2 CM2 0.0 to 50.0 (A)
This function is to display the measurement value of CT 2.
■ CT 2 abnormal current value setting
SEt12
CT
Setting content Initial value
3 Ct2
0.0 to 30.0 (A)
Function turned off at 0.0 (A) setting
0.0
This function is to set the current value for the CT 2 abnormality.
For the target setting value, see section “5.4.7 Current transformer (CT) abnormality function” on pages 5-40 to 44.
