■ Output section
* The number of outputs is 7 at most, which can be assigned individually for control output, event
output, RUN/RDY output, timer output and transmission output.
(Assignment of outputs is to be designated at order placement.)
★ Output (OUT) 1 and output (OUT) 2
* Target connection of output can be set.
Primary output, secondary output, event output, RUN output, RDY output, timer 1 output, timer 2
output, timer 3 output, transmission output and end output
★ Output (OUT) 3, output (OUT) 4, output (OUT) 5, output (OUT) 6 and output (OUT) 7
* Target connection of output can be set.
Primary output, secondary output, event output, RUN output, RDY output, timer 1 output, timer 2
output, timer 3 output and end output
* Some specifications are not selectable, depending on the model. Check them on the model table.
★ Selection of output types
* Outputs 1 and 2
Relay contact 250 VAC, 3 A (resistance loads) and 1a contact
Voltage for SSR drive 0 - 12 VDC (load resistance: 600

or greater)
Open collector 24 VDC, 100 mA (load current)
Voltage 0 - 5 VDC, 1 - 5 VDC and 0 - 10 VDC
(resistance loads: 1 k

or greater)
0 - 1 VDC and 0 - 10 mVDC (load resistance: 500 k

or greater)
Current 4 - 20 mADC (load resistance: 600

or less)
* Outputs 3, 4, 5, 6 and 7
Relay contact 250 VAC, 1 A (resistance loads) and 1a contact
Open collector 24 VDC, 100 mA (load current)
* Transmission output function selection
PV (measurement value) output
SV (setting value) output
MV 1 (primary operating amount) output
MV 2 (secondary operating amount) output
Control SV (setting value) output
Forward and reverse operations can be switched over for all the outputs above.
★ Selectable outputs for each model
Output 1 Output 2 Output 3 Output 4 Output 5 Output 6 Output 7
TTM-204       
TTM-205       
TTM-207       
TTM-209       
* TTM-204: Outputs 3 and 4 are for common shared.
* TTM-207: Outputs 3 and 4 are for common shared.
When DI 3 is selected, output 7 will not be selectable.
* TTM-205 and 209: Outputs 3 and 4 are for common shared.
