48-7009-E 7-31
7.5.15 Program function setting mode (SET 21)
Setting data Character Setting (monitor) value Initial value Unit
Setting
value
Blind
Operating type
setting
C/P
0: Constant value run mode
1: Program run mode
0 None
Program mode
setting
PGMd
0: Program mode 1 (without
power failure compensation)
1: Program mode 2 (without
power failure compensation)
2: Program mode 1 (with power
failure compensation)
3: Program mode 2 (with power
failure compensation)
Program 1: Control stops after a
run ends.
Program 2: Control continues
after a run ends.
0 None
Power failure
compensation range
setting
PoC
Setting value range
Thermocouple/resistance
temperature detector input
0.0 to 999.9 (

C)
0 to 999 (  C)
Voltage/current input
0 to 9999 (digit)
If the setting is 0, the power failure
is always restored.
0

C
Digit
Time unit setting H/MP
0: Step time (hour; minute)
1: Soak time 1 (hour; minute)
2: Soak time 2 (hour; minute)
3: Step time (minute; second)
4: Soak time 1 (minute; second)
5: Soak time 2 (minute; second)
Step time: To the next step after
predetermined time elapses
Soak time 1: Counted with a
falling-in within the set WAIT
range
Soak time 2: Counted only in the
set WAIT range
0 None
WAIT range setting WAIt
Setting value range
Thermocouple/resistance
temperature detector input
0.0 to 999.9 (

C)
0 to 999 (

C)
Voltage/current input
0 to 9999 (digit)
If
“0” is set for Soak time 2, then
operation is for Soak time 1.
2 None
Note SET 21 is selectable only on Ver3.xx or later.
