48-7009-E 7-16
7.5.5 Control setting mode (SET 04) (1/4)
Setting data Character Setting (monitor) value Initial value Unit
Setting
value
Blind
Bank switchover bANK
0: Bank 0
0 None
1: Bank 1
2: Bank 2
3: Bank 3
4: Bank 4
5: Bank 5
6: Bank 6
7: Bank 7
Bank upper limit
setting
bANKH 0 to 7 7 None
Control setting SV SLL to SLH 0

C
SV limiter upper limit SLH
Temperature:
(SLL + 5.0) to SV setting range
upper limit
(SLL + 5) to SV setting range
upper limit
Analog:
(SLL + 50) to SV setting range
upper limit
1200

C
Digit
SV limiter lower limit SLL
Temperature:
SV setting range lower limit to
(SLH - 5.0)
SV setting range lower limit to
(SLH - 5)
Analog:
SV setting range lower limit to
(SLH - 50)
0

C
Digit
Control mode Md
RDY: Control stop
RUN: Control start
MAN: Manual
TIME 1: Timer 1 operation
TIME 2: Timer 2 operation
TIME 3: Timer 3 operation
RUN None
Control type CNt
0: Primary nonexistent
Secondary nonexistent
1: Primary PID control
Secondary nonexistent
2: Primary ON/OFF control
Secondary nonexistent
3: Primary PID control
Secondary PID control
4: Primary PID control
Secondary ON/OFF control
5: Primary ON/OFF control
Secondary ON/OFF control
6: Primary position proportional
Secondary position
proportional
1 None
