48-7009-E 7-19
7.5.5 Control setting mode (SET 04) (4/4)
Setting data Character Setting (monitor) value Initial value Unit
Setting
value
Blind
Secondary control
at-abnormality
operating amount
FAL2
Digital output: 0.0 to 100.0
Analog output: -10.0 to 110.0
0.0 %
Secondary control
loop anomaly PV
threshold
tS2
Temperature: 0.0 to 999.9
0 to 999
Analog: 0 to 9999
0

C
Digit
Secondary control
loop anomaly MV
threshold
MS2 MLL2 to MLH2 100.0 %
Secondary control
loop anomaly PV
change threshold
PS2
Temperature: 0.0 to 999.9
0 to 999
Analog: 0 to 9999
0

C
Digit
Secondary control
loop abnormality time
LoP2 0 to 9999 0 Second
Secondary control
sensitivity
C2
Temperature: 0.0 to 999.9
0 to 999
Analog: 0 to 9999
0
 C
Digit
Secondary control
off-point position
CP2
Temperature: -999.9 to 999.9
-999 to 999
Analog: -9999 to 9999
0

C
Digit
Secondary control off
protection timer
Fdt2 0 to 99 0 Minute
Secondary control
protection on timer
Ndt2 0 to 99 0 Minute
Manual reset Pbb 0.1 to 100.0 0.0 %
Dead band db
Temperature: -999.9 to 999.9
-999 to 999
Analog: -9999 to 9999
0

C
Digit
Ramp time RMP
Temperature: 0.0 to 999.9
Analog: 0 to 9999
0.0
 C/minute
Digit
/minute
Valve motor stroke
time
VLt 0.1 to 999.9 3.0 Second
Valve motor drive
dead band
Vdb 0.0 to 100.0 1.0 %
Post-AT initial
opening ratio
ASP 0.0 to 100.0 50.0 %
Note (Ndt2) is selectable only on Ver3.xx or later.
Note The (RMP) function will turn OFF at setting value "0" or "0.0".
