48-7009-E 6-77
6.14 PROGRAM SETTING
■ Setting No. of Steps to be Used / Step SV＊ Setting / Step Time＊ Setting
ＳＥｔ２２
ＰＲＯＧ
SETTING CONTENTS
INITIAL
VALUE
1 ＳｔＥＰＮ
Setting of no. of steps used 3
8
Setting Value Range n=1～8
2 Ｓｔ＊ｂＫ
Step＊ Designated Bank Setting 3
0 Setting Value Range St*BK=0～7
*=1～(StEPN Setting Value)
3 ＳＶ＊
Step SV＊ Setting 3
0
Setting Value Range SV*=SLL～SLH
*=1～(StEPN Setting Value)
※ When the SLL and SLH is set at the Bank, the
value of the SLL,SLH will be set on each bank.
4 ｔＩＭ＊
Step Time＊ Setting 3
00:00 Setting Value Range TIM*=00:00～99:59
*=1～(StEPN Setting Value)
Sets the Program Step Data of the Program Setting Mode.
＊
1 No. of Steps Used Setting (StEPN)
This is to set the “Max. No. of Steps” which is used in the programmed operation.
＊
2 Step＊ Designated Bank Setting (St＊bK)
This is to set the “Bank Nos.” which the system refers in every step.
＊
3 Step SV＊ Setting (SV＊)
This is to set the target value (temperature or analog value) of the control in every steps.
＊
4 Step Time＊ Setting (tIM＊)
This is to set the Step Duration Time of every steps.
The next page shows the behavior diagram of the “No. of Steps Used Setting / Step SV＊ Setting / Step Time＊ Setting”.
