48-7009-E 6-59
6.7 DI setting
■ DI function setting
SEt13
dI
Setting content Initial value
1 dIF
Press the MODE key for making a setting effective (including reverse feed).
0000
****
||||
|||+-- DI 1 setting (settable when an option existent)
||+--- DI 2 setting (settable when an option existent)
|+---- DI 3 setting (settable when an option existent)
+----- DI 4 setting (settable when an option existent)
Active
0 None None
1 Bank switchover Bank switchover
2
When Constant operation
Mode
MD
When Program Mode
Start
When Constant operation
Mode
READY
When Program Mode
stop
3 MD MANUAL
4 Reverse operation Forward operation
5 AT stop AT start
6 Timer stop Timer start
7 Constant Operation Mode Program Mode 3
8 －
Step Forward 3
(during program mode)
9 －
Pause 3
(during program mode)
A nerlock － 3
Set the DI function.
0: No DI function
1: Bank switchover is executed.
Bank selection table per DI 1 state
DI1 DI3 DI2 DI1
0 Bank 0 0 0 0 Bank 0
1 Bank 1 0 0 1 Bank 1
0 1 0 Bank 2
DI2 DI1 0 1 1 Bank 3
0 0 Bank 0 1 0 0 Bank 4
0 1 Bank 1 1 0 1 Bank 5
1 0 Bank 2 1 1 0 Bank 6
0: Inactive
1: Active
1 1 Bank 3 1 1 1 Bank 7
The parameters change right after switchover when the bank is changed per DI.
2: ＜During Constant Operation Mode＞ Switching of Control Mode and STOP.
＜During the Program Mode＞ Switching of In-Operation and Operation Stop.
3: Switching of AUTO & MANUAL is done
4: Switching of Output Movement (forward / reverse movement) is done.
5: The Star & Stop of Auto-Tuning of PID Control is done.
Maintain the DI to active condition until the auto-tuning is completed.
In case the operation is suspended half-way, the auto-tuning will stop.
