TOHO ELECTRONICS TTM200 - Manual (Page 256)

48-7009-E 7-25
7.5.8 CT setting mode (SET 12)
Setting data Character Setting (monitor) value Initial value Unit
Setting
value
Blind
CT 1 target
connection
CI1
1: Connected to OUT 1
2: Connected to OUT 2
3: Connected to OUT 3
4: Connected to OUT 4
5: Connected to OUT 5
6: Connected to OUT 6
7: Connected to OUT 7
1 None
CT 1 current value
monitor
CM1 0.0 to 50.0 A
CT 1 abnormal
current value setting
Ct1
0.0 to 30.0
(Turned off with 0.0)
0.0 A
CT 2 target
connection
CI2
1: Connected to OUT 1
2: Connected to OUT 2
3: Connected to OUT 3
4: Connected to OUT 4
5: Connected to OUT 5
6: Connected to OUT 6
7: Connected to OUT 7
1 None
CT 2 current value
monitor
CM2 0.0 to 50.0 A
CT 2 abnormal
current value setting
Ct2
0.0 to 30.0
(Turned off with 0.0)
0.0 A
