■ Regarding the “program run mode” operation list table
“Program run” is categorized into “before run,” “run in process” and “run end” depending on run status,
for which the operable keys vary. “Operation list table” indicates key operations corresponding to the
status.
“In-stop” indicates before a run, “run in process” a run in process and “After-end” a run ended.
The INDEX ① to ⑯ in the diagram corresponds to “operation and display of a program run” in the
previous page.
< Operation list table (1/3) >
INDEX Screen
Key operation
Behavior
Run status Type Operation method
① Program run
screen Before run MODE Prolonged press of 2 seconds To the setting mode
Run in process MODE Depression To step SV value display screen
Run end FU1-5 Depression Follows the function key setting.

Prolonged press of 2 seconds No action

Prolonged press of 2 seconds No action
 Depression No action
 Depression No action
② Step SV value
screen Before run MODE Prolonged press of 2 seconds To the setting mode
MODE Depression To step time monitor screen
FU1-5 Depression Follows the function key setting.
 Prolonged press of 2 seconds Run start
 Prolonged press of 2 seconds No action

Depression No action
 Depression No action
③ Run in process MODE Prolonged press of 2 seconds To the setting mode
MODE Depression To step time monitor screen
FU1-5 Depression Follows the function key setting.

Prolonged press of 2 seconds No action
 Prolonged press of 2 seconds No action
 Depression Setting: SV value increased

Depression Setting: SV value decreased
④ Run end MODE Prolonged press of 2 seconds To the setting mode
MODE Depression To step time monitor screen
FU1-5 Depression Follows the function key setting.

Prolonged press of 2 seconds No action

Prolonged press of 2 seconds Run stop *4

Depression No action
 Depression No action
Note *4: This key operation is ineffective if “start/stop” is set for the FUNC key or DI.
