TOHO ELECTRONICS TTM200 User Manual

Page 229

48-7009-E

6-81

■

Bank Automatic Switching Source Setting

ＳＥｔ２３

ＺｂＮＫ

Setting Contents

Initial

Value

ｂＡＳ

Bank Automatic Switching Source Setting

Function

*0 Select SV value
*1 Select ramp SV value

*2 Select PV value

Control Mode Interlock Function

0* All Mode
1* RUN/MAN Mode Only
2* RUN Mode Only

※

Select the source for the SV value to which the
Bank Automatic Switching will be done.

※

When “SET04 bANKH=0”, the setting will be
invalid.
There will be no indication either.

※２

Bank Automatic Switching Source Setting (bAS)

Select source to which the Bank Automatic Switching will be done. Switch the bank in accordance with
the source selected.

Setting Range：When 0, select SV Value ＜Local and Remote (only Option Y)＞

：When 1, select ramp SV value.
：When 2, select PV value

NOTE: The behavior of AT (Auto-Tuning) when (bAF = 1).

・

Regardless of the source setting to which the Bank Automatic Switching will be done, it will select

SET04(SV). After the completion of the AT (Auto-Tuning), it will go back to Bank Automatic
Switching Source Setting (bAS).

・

In case the Zone Threshold＊Setting (PM＊) is set, at the same time the parameter (P, I, D) is set to the
bank, the PID value obtained from the AT (Auto-Tuning) will be reflected to the Bank No. according to
the threshold.
