48-7009-E 5-66
Set the ON delay timer, OFF delay timer and repeat count for a timer.
Set the ON delay timer for Timers 1 to 3 using [oNt 1 to oNt 3].
Set the OFF delay timer for Timers 1 to 3 using [oFt 1 to oFt 3].
Set the repetition count for Timers 1 to 3 using [RUN 1 to RUN 3].
(ON delay timer/OFF delay timer/repeat count setting)
Setting content
Initial
value
4
oNt1
to
oNt3
0:00 to 99:59 (hour: minute or minute: second) 0:00
5
oFt1
to
oFt3
0:00 to 99:59 (hour: minute or minute: second) 0:00
6
RUN1
to
RUN3
0 to 99 counts (0 for unlimited counts) 1
Note If [tMF 1 to tMF 3] (function setting) is used for the SV start, the ON delay timer screen is not
displayed.
Remaining time of Timers 1 to 3 is displayed. Timers can be started from this screen.
(Remaining time monitor)
Setting content
Initial
value
7
tIA1
to
tIA3
0:00 to 99:59 (hour: minute or minute: second)
Start/stop of timer using / key
0:00
• When the ON delay timer and OFF delay timer are set, the setting value for the ON delay timer is
displayed.
• When only the OFF delay timer is set, the setting value for the OFF delay timer is displayed.
• When the timer starts, the remaining time for the ON or OFF delay timer currently counting down is
displayed.
When the timer completes the countdown, “0:00” is displayed.
• For display during a program run, see Section 5.5.6 Explanation of the screen display and operation
of a program run (P5-56 to 60).
