TOHO ELECTRONICS TTM200 User Manual
Page 214
48-7009-E
6-66
■ Communication address setting
SEt17
CoM
Setting content
Initial value
4
AdR
TOHO protocol
1 to 99 (stations)
1
MODBUS protocol
1 to 247 (stations)
Set the address for communication.
Take care that no identical numbers are assigned for more than one unit of equipment.
For details of communication, see “TTM-200 series operation manual - communications.”
■ Response delay time setting
SEt17
CoM
Setting content
Initial value
5
AWt
0 to 250 (ms)
0
Set the response delay time in communication.
Response delay time in communication is set for the time taken from when a host computer completes transmission of
“request message” until when it gives up the line to become in the input state.
Note Communication may not be properly executed when the response delay time setting is for too short a time.
Note For the actual operation time, processing time of the product is added on the response delay time.
For details of communication, see “TTM-200 series operation manual - communications.”
■ Communication switchover setting
SEt17
CoM
Setting content
Initial value
6
Mod
0
Write inhibit
1
1
Writable
2
Concurrent temperature ascent master
3
Concurrent temperature ascent slave
Set the communication switchover.
When “0” is set, writing is inhibited.
When “1” is set, writing is enabled.
When “2” is set, master for the concurrent temperature ascent is established.
When “3” is set, slave for the concurrent temperature ascent is established.
For details of communication, see “TTM-200 series operation manual - communications.”
